SPCP2800 GATES PREDATOR® Endless V-belts GATES

Specifications

• Weight (kg/m) 1.13
• Belt type Narrow wrapped
• Suitable for automotive Yes
• Profile SPCP
• Outer length (mm) 2830
• Belt height (mm) 18
• Belt width (mm) 22
• Standard DIN7753
• Minimum pulley diameter (mm) 224
• Antistatic No
• Inner length (mm) 2723
• Track length (mm) 2800
• Belt material Chloroprene
• Cord material Aramid
• Units pc
• Belt profile SPCP
• Weight (kg) 1.13
• Description (EN) Made to take on your toughest jobs, Predator® Single Belts are the markets' leading heavy duty V-belts. The stronger than steel extra heavy-duty belt construction is designed to handle high horsepower motors, frequent shock loads, high heat, and the harshest operating environments in extremely demanding applications. They provide extraordinary high impact strength, capacity, and wear resistance. Unique in their extreme robustness and high load carrying capability they are unrivalled. Aramid Tensile Cords limit stretch while providing extraordinary strength and durability. Minimal re-tensioning reduces maintenance needs. Meets RMA oil and heat resistance standards.
• Minimum temperature (°C) -30
• Maximum temperature (°C) +60
• EAN code 5414465579950
• Custom code 4010.3900.90
• Number of ribs 1
• Status Normal
• Colour BLACK
• Country of origin PL
• Construction Bandless
• beltInside Smooth
• beltBackSide Smooth
• OC(mm) 2835
• Corner 40
• Reach/ROHS Compliance REACH and RoHS 2
• ISO1 standard 1813
• Brand GATES
• Weight (kg/m) 1.13
• Profile SPCP
• Outer length (mm) 2830
• Belt width (mm) 22
• Antistatic No
• Inner length (mm) 2723
• Belt material Chloroprene
• Belt profile SPCP
• Weight (kg) 1.13
• Minimum temperature (°C) -30
• Maximum temperature (°C) +60
• Country of origin PL
